Wide Range of Pipe Cutting
____
The equipment has a wide range of applications and can easily handle tubes of different specifications; It can cut round tubes, oval tubes, square tubes, D-shaped tubes, channel beams, angle beams, H beams, T beams, etc.
Small Investment, Big Return
____
The structure is simple, the installation is convenient, and it can be put into production quickly; The processing speed is fast, the cutting performance is powerful, and the tube processing is cost-effective.
Classic two-chuck structure design, surrounded by safety protection; Small footprint, large utilization of plant space.
Classic Design, Compact and Practical
____
Pneumatic Precision Chuck
____
Pneumatic clamping, automatic centering, stable clamping; Special support frame to avoid sagging and deformation of tubes.
Optional Automatic Feeding System
____
According to the range and type of tube to be processed, a fully automatic/semi-automatic feeding unit can be selected; Save manpower, reduce labor intensity, and further improve production efficiency.
| Model | DB-TL 6016 | DB-TL 6020 |
| Laser Output Power | 2000w~3000w | |
| Effective Cutting Diameter Of Round Tube | φ10mm-φ160mm | φ10mm-φ225mm |
| Effective Cutting Diameter Of Square Tube | □10-□160mm | □10-□225mm |
| Positioning Accuracy | ±0.1mm | |
| Repeat Positioning Accuracy | ±0.1mm | |
| Maximum Simultaneous Positioning Speed | 110m/min | |
| Maximum Acceleration | 1.5G | |
