CNC NCP Series

NCP Series CNC Synchronize Hydraulic Press Brake

NCP100-32

“Full welded steel frame, stress relieved by vibration process.”

The parallelism of the ram (Y1,Y2) achieved with the use of advancedproportional valve control and the signal feedback by the linear encoder.Synchronization of Y1 and Y2 axis is within 0.01mm,the bending angel is 0.5°.

  • Design Of LED Cold Light Illumination
  • High-pressure Precision Filters
  • Imported Hydraulic System
  • High Precision Ball Screw Guide
  • Front Supporting Device

NCP160-40

“Full welded steel frame, stress relieved by vibration process.”

The parallelism of the ram (Y1,Y2) achieved with the use of advancedproportional valve control and the signal feedback by the linear scales. Synchronization of Y1 and Y2 axis is within 0.01mm,the bending angel is 0.5°

  • Components Imported From The European and Germany
  • Front Supporting Device

The parallelism of the ram (Y1,Y2) achieved with the use of advancedproportional valve control and the signal feedback by the linear scales. Synchronization of Y1 and Y2 axis is within 0.01mm,the bending angel is 0.5°

  • Front Supporting Device
  • Safely laser guard
  • Auto-stopper moving

NCP200-32

“Full welded steel frame, stress relieved by vibration process”

Lorem Ipsum

“Water Cooler”

Dual temperature and dual control, circulating water circuit, can quickly cool the internal pipeline cavity of the welding head, while cooling the laser.

Lorem Ipsum

“Standard 10 Meters Optical Fiber”

It is conventionally equipped with 10-meter optical fiber, which can realize long-distance, flexible welding in large areas and reduce operating limitations.

Lorem Ipsum

“360° No Dead Angle Micro Welding”

After the laser beam is focused, a small spot can be obtained, which can be accurately positioned, and is applied to micro and small workpieces that are automatically produced in large quantities. Mainly for the welding of thin-walled materials and precision parts, it can realize spot welding, stitch welding, tailor welding, sealing welding, etc. High aspect ratio, small weld width, small heat aff
ModelOR-HW1000OR-HW1500OR-HW2000OR-HW3000
Laser Power1000W1500W2000W3000W
Laser Wavelength1064±10nm
Output Power Stability±2%
Power Requirements220V/380V
Machine Power≤5.5KW≤6.5KW≤8.5KW≤12.5KW
Operating Environment temperature range10-40℃
Working Environment humidity range<70% No condensation
Welding Line Requirements≤0.5mm
Max Welding Speed0-120mm/s
Machine Size1000×630×910mm
1200×630×960mm

Spesification Table
